P5 Indoor LED Screen

P5 indoor LED screen is used to display video indoors, the product price is good, cost-effective, clear display screen, no length and width restrictions, can be made into a large area display. One square meter pixel density 40,000 dots.

Description

P5 indoor full color LED display is the most used LED display at present, mainly used for playing video indoors with unrestricted area. It has the features of high cost performance, no seam, customizable size, clear display and strong functional expansion. It is widely used in various occasions.

The best viewing distance is ≥5M.



Advantages of our P5 indoor LED screen


High quality LED beads

Gtseen's P5 Indoor LED screens are made of high quality components with recommended Nationstar or Kinflight RGB LED beads, which have very low failure rates and very low display light decay.


High-performance driver IC

Adopt high refresh driver IC, refresh rate of 3840Hz, shooting display screen, no scan line, color 14BIT grayscale, better viewing effect.刷新.jpg

Color 14BIT ,65536 grayscale  , better viewing effect.灰度.jpg

Larger view

The P5 indoor LED display has a wide viewing angle of 170° to meet the needs of viewing at various angles.


Production technology advanced

Adopt fully automatic production line production, from lamp surface SMD to module assembly, each process is layer by layer to ensure the reliability of each lamp bead, driver IC, no false welding, no failure LED lamp beads.


Very easy to maintain

The modules are attached to the structure with magnets, and the modules are removed from the front. Installation and maintenance are easy as we provide quick disassembly tools.


True natural color

LED screen control system has the technical characteristics of color reproduction, arbitrary frequency multiplication, low brightness and high gray. Through brightness uniform correction, grayscale nonlinear conversion, noise reduction processing, image enhancement processing and dynamic pixel processing, the depth of signal processing is increased to ensure the color reproduction of the display.


Application

Indoor LED screen, high pixel density, clear and delicate display, widely used in indoor display. For example: command center, public propaganda, radio and television center, meeting room, shopping mall, hotel, etc.


Product parameters

Pixel Configuration

SMD2020

Pixel Pitch(mm)

5

Minimum Viewing Distance(m)≥5

Pixel Density(point/ m2)

40,000

Module Resolution (W×H)

64×32

Module Size (mm)

320(W)×160(H)

Module Weight(kg)

0.3

Module Maximum power(W)

30

Cabinet Size(W×H)

3×6

Cabinet Density (W×H)

192×192

Cabinet Combination(mm)

960(W)×960(H)×120(D)

Cabinet Area(m2)

0.9216

Cabinet Weight(kg)

20

Cabinet Planeness(mm)

≤0.2

Cabinet materialIron/Al

Single Lamp Luminance Correction

Y

Single Lamp Color Correction

Y

Brightness(CD/㎡)

800(6500K)

CCT(K)

3200—9300

Viewing Angle(H/V)

160/160

Luminous point Center Distance Deviation

<2.5%

B/CCT Uniformity

≥98%

Contrast

5000:1

Max. Power Consumption(W / m2)

800

Middle Power Consumption(W / m2)

150-250

Operation Power

AC90〜264V,47-63(Hz)

FPS(Hz)

50&60

LED Drive Method

1/16s

Gray

65536

Refresh Frequency(Hz)

≥3840

Color Depth

14bit

Video Playback Funct

2KHD,4KHD

Work T/ H(℃/ RH)

-20 – 60/10%-85%RH

Store T/ H(℃/ RH)

-20 – 60/10%-85%RH

Authentication

CCC,TUV-CE,FCC

Reasons for choosing Gtseen


Our staff has 10 years of experience in the field of LED display manufacturing. We can produce high quality and reliable LED display products for you, and we can customize the products to meet your requirements. Perfect after-sales service, for each batch of LED display, provide 5% spare parts for your order replacement. Products have passed CE RoHs, FCC certification.


Professional production workshop, standard production process.

We have module and whole screen production capacity, the product manufacturing process is fully automated to ensure stable and reliable products.


Good packaging protection for long distance transportation.

Our exported displays are packed with foam surface and wooden box, or air box, and the packaging is randomly checked for vibration test before shipment to ensure the products are delivered to you safely.



Frequently Asked Questions


Q1. Are the products customizable?

Answer: Yes, we can customize our products according to customers' requirements, you just need to provide us with project details, such as exterior shape, size, for outdoor or indoor use, fixed installation or portable rental type, minimum viewing distance, etc.


Q2: How do you ensure the quality of your LED display products?

Answer: We have professional R&D team and skilled quality control team with standard process to ensure quality products, we do 100% aging test and waterproof test before delivery. We provide 2 years warranty for LED screen.


Q3:How about your delivery time?

Answer: It takes 10 to 15 days after receiving the advance payment.


Q4: Can I print my logo on the LED screen?

Answer:Yes. Please send me the logo picture before we produce, and confirm the appearance with you after we produce the sample.


Q5. What are your payment terms and trade terms?

Answer: Payment terms: T/T 30% as deposit, 70% before delivery. After production, we will send you the pictures and videos of the products to confirm, meanwhile, you are welcome to come to the factory to inspect the goods.

Trade terms: EXW, FOB, CIF, DDP, DDU, will follow your requirements.
